KC1000YP-4R wood sanding machine before or after paint kitchen cabinet MDF board sanding machine

Name: KC1000YP4R wood sanding machine before or after paint kitchen cabinet MDF board sanding machine
Brand: KCARPENTER
Price: 2700 USD

China KC1000YP-4R wood sanding machine before or after paint kitchen cabinet MDF board sanding machine wholesale

Brand Name : KCARPENTER

Model Number : KC1000YP-4R

Certification : ISO,CE

Place of Origin : Shandong, China

MOQ : 1 SET

Price : 2700-9000usd/set

Payment Terms : TT/ LC

Supply Ability : 50set/month

Delivery Time : 15 days

Packaging Details : Plywood box

Contact Now

KC1000YP-4R wood sanding machine before or after paint kitchen cabinet MDF board sanding machine

https://youtu.be/4RX0dtHIXA0

KC1000YP-4R wood sanding machine before or after paint kitchen cabinet MDF board sanding machine

Model	KC1000YP-4R
Sandpaper rollers quantity	4 pcs rollers
Press roller quantity	6pcs
inverters	5.5kw *3pcs (each 2 adjacent sandpaper rollers use 1 inverter,9 vertical brushes use 1 inveter)
Motors	2.2kw*5pcs
Conveyor motor size	1.1kw
VFD speed control	5-30m/min
Max. working width	1000mm
Sandpaper brand	China
Horizontal sandpaper rollers diameter	300mm
Rollers center distance	330mm
Vertical brush diameter	280mm
Each 2 rollers turning direction	opposite
Power	380V 50HZ 3PHASE
Packing size	300015001600mm
G.W.	1800kg

KC1000YP-4R wood sanding machine before or after paint kitchen cabinet MDF board sanding machine

Model

KC1300-6P (with 6 sandpaper rollers)

KC1300-4P (with 4 sandpaper rollers)

https://youtu.be/-zKtWYN56iU (6 sandpaper rollers)

https://youtu.be/K1Uo0u1UKxw (special customized by clients final effect picture in the end)

KC1000YP-4R wood sanding machine before or after paint kitchen cabinet MDF board sanding machine

Specification:

Motor's rpm control by inverters,wire brush roller inverter 7.5kw,dupont silk inverter 7.5kw, 4 sandpaper rollers has 2 inverters each 5.5kw .
Sandpaper strips: grit 400,600 install on machine.
Machine main body and motors inverters warranty for 1 year, 380V 50HZ 3Phase.

Model	KC1300-6P
Sandpaper rollers quantity	6 pcs
Press roller quantity	6pcs
inverters	5.5kw *4pcs (each 2 sandpaper roller use 1 inverter)
Motors	2.2kw*6pcs
Conveyor motor size	1.1kw
VFD speed control	5-30m/min
Max. working width	1300mm
Each rollers diameter	300mm
Rollers center distance	330mm
Each 2 rollers turning direction	opposite
Power	380V 50HZ 3PHASE
Packing size	300018001450mm
G.W.	1800kg

Sandpaper specification

High quality sandpaper

Grit: 180,240,320,400,600

Quantity: Each roller 20 strips

Length:1338mm

KC1000YP-4R wood sanding machine before or after paint kitchen cabinet MDF board sanding machine

Other polishing machine models

1000-6P , 1300-6P, 6 sanding rollers, working width 1000mm, 1300mm customized

Working video link: https://youtu.be/-zKtWYN56iU

KC1000YP-4R wood sanding machine before or after paint kitchen cabinet MDF board sanding machine

1000-4YP ,sanding machine with 4sanding rollers, 9 sanding discs. 5 discs +4 discs in 2 lines.

Working video link: https://youtu.be/8bC8nx1T0OY

KC1000YP-4R wood sanding machine before or after paint kitchen cabinet MDF board sanding machine

Manual operate Single head wood sanding machine

https://youtu.be/99PQQ578ihY

https://youtube.com/shorts/eNPpq1IgBOY?feature=share

KC1000YP-4R wood sanding machine before or after paint kitchen cabinet MDF board sanding machine

2 heads of sandpaper rollers manual operate wood sander

Test video: https://youtu.be/Yhp_SwJeGD8

KC1000YP-4R wood sanding machine before or after paint kitchen cabinet MDF board sanding machine

High quality wood sander/with all can pull out

https://youtu.be/PRhxQZC0_mI

KC1000YP-4R wood sanding machine before or after paint kitchen cabinet MDF board sanding machine

wood brush sander
KC1000-6SD	https://youtu.be/gYaylItRp3E
KC1000-6CD	https://youtu.be/PRhxQZC0_mI
KC1000-2Y-4P	https://youtu.be/TTvt6nunb1k
wood brush disc	https://youtu.be/HcGj8gajBgc
how to change sandpaper	https://youtu.be/NXdGCNXtDVY
KC1000-5R	https://youtu.be/erE15dXBW_k
UV production line sander for door	https://youtu.be/OUoFuDPcpaE
9+2 wood sander	https://youtu.be/EOnrCeyduH4
9+9+2 wood sander	https://youtu.be/70WF3TyziRA
9+2 wood sander	https://youtu.be/MWlPUrDe5H8
Solid door wood sander	https://youtu.be/JwTJE-xZvgY
6SD for solid door	https://youtu.be/1EZBeMpEZx8
For engraved solid wood pattern	https://youtu.be/zJib4YVMDrk
Solid wood sander 2	https://youtu.be/gkoQ4161fWM
Single head small sander	https://youtu.be/99PQQ578ihY
Engraved wood sander	https://youtu.be/tMaowaGmG0M
Glue polishing machine	https://youtu.be/JztDI5bnTj4
Wide belt sander R-R630	https://youtu.be/8_J9MrbRcUA
Vacuum membrane press machine
video 1	https://youtu.be/Cn89dvSj7F0
video 2	https://youtu.be/jQ7pUOa2VEI
video 3	https://youtu.be/04Tv4fP7kaw
video 4	https://youtu.be/jQ7pUOa2VEI


Edge banding machines
KC360D auto edge bander	https://youtu.be/8c47jKVxxIA
KC4180D Big auto edge bander	https://youtu.be/h4Wdt57xAMg
Mini curve edge bander	https://youtu.be/MD9pgo1NhhA
Mini straight board edge bander	https://youtu.be/Oeqj2tR8f7A
MINI curve edge bander 2	https://youtu.be/7MFkycCxVPQ
Edge banding tape heating box	https://youtu.be/Qpdq97nBIX4
KC4108 auto edge bander	https://youtu.be/O43r7xfV_6c
KC4108 auto edge bander2	https://youtu.be/_pCNoPkr4vA
MB505 auto edge bander cheaper	https://youtu.be/6pAdLtami-E
MB505D auto edge bnader	https://youtu.be/pbbWD0GbzMU
MB505 auto edge bander 3	https://youtu.be/jMuXxVJ6nNU
KC4008 Bevel edge banding machine	https://youtu.be/zFQTutJgwC8

Sliding table saw
MJ6130TY	https://youtu.be/WcsLQk1pRC0
MJ6130TY	https://youtu.be/xv-MxqRW6E8
MJ6130TY	https://youtu.be/enrtKYPnIfQ
